Barcode
Generate barcodes from a wide range of different formats.
Endpoint
The API can be called via POST method. The endpoint returns an image in the chosen format.
POST/v1/barcode
curl -X POST https://api.apistax.io/v1/barcode \
-o 'qr-code.webp' \
-H 'Authorization: Bearer API_KEY_HERE' \
-H 'Content-Type: application/json' \
-d '{ "format": "QR_CODE", "content": "Example QR code content"}'
Parameters
The following parameters can be used as JSON fields in the POST request.
format: String
The format of the barcode to be generated. The available types of barcodes can be found under barcodes.
content: String
The content to be encoded in the barcode.
width: Integer = 1
The minimum width of the generated barcode. Must be between 1 and 2000 pixels.
height: Integer = 1
The minimum height of the generated barcode. Must be between 1 and 2000 pixels.
foregroundColor: String = #000000
The foreground color of the barcode. The default is black.
backgroundColor: String = #FFFFFF
The background color of the barcode. The default is white.
output: String = WEBP
The image type in which the barcode is to be generated. The default is WEBP. Possible types are PNG, JPEG, GIF,
TIFF and WEBP.
options: Object
Depending on the format of the barcode, there are various options.
AZTEC
characterSet: String
The character set to be used for encoding. For example, UTF-8, US-ASCII, etc.
errorCorrection: Integer
The error correction level as a percentage. The recommended value is 23%.
layers: Integer = 0
Specifies the required number of layers for the code. A negative number (-1, -2, -3, -4) specifies a compact code. 0 indicates to use the minimum number of layers. A positive number (1, 2, .. 32) specifies a normal code.
CODE_128
compact: Boolean
Specifies whether to use compact mode. This can yield slightly smaller bar codes.
DATA_MATRIX
compact: Boolean
Specifies whether to use compact mode. This can yield slightly smaller codes. This option and forceC40 are mutually
exclusive.
forceC40: Boolean
Forces C40 encoding for data-matrix. This option and compact are mutually exclusive.
gs1Format: Boolean
Specifies whether the data should be encoded to the GS1 standard.
characterSet: String
The character set to be used for encoding. For example, UTF-8, US-ASCII, etc.
shape: String
Specifies the matrix shape. Possible values are NONE, SQUARE and RECTANGLE.
PDF_417
compact: Boolean
Specifies whether to use compact mode.
autoEci: Boolean
Specifies whether to automatically insert ECIs when encoding.
errorCorrection: Integer
Specifies what degree of error correction to use. The value must be between 0 and 8, where 8 means maximum error correction and 0 means minimum error correction.
characterSet: String
The character set to be used for encoding. For example, UTF-8, US-ASCII, etc.
compaction: String
Specifies what compaction mode to use. Possible values are AUTO, TEXT, BYTE and NUMERIC.
QR_CODE
compact: Boolean
Specifies whether to use compact mode.
gs1Format: Boolean
Specifies whether the data should be encoded to the GS1 standard.
version: Integer
Specifies the exact version of QR code to be encoded. The value must be between 1 and 40.
characterSet: String
The character set to be used for encoding. For example, UTF-8, US-ASCII, etc.
errorCorrection: String
Specifies what degree of error correction to use. Possible values are L (~7% correction), M (~15% correction),
Q (~25%
correction) and H (~30% correction).
If most parameters are utilized, an example curl request could look like this:
curl -X POST https://api.apistax.io/v1/barcode \
-o 'qr-code.webp' \
-H 'Authorization: Bearer API_KEY_HERE' \
-H 'Content-Type: application/json' \
-d '{
"format": "QR_CODE",
"content": "Example QR code content",
"width": 200,
"height": 200,
"foregroundColor": "#A3A3A3",
"backgroundColor": "#FFFFFF",
"output": "PNG",
"options": {
"compact": false,
"gs1Format": false,
"version": 40,
"characterSet": "UTF-8",
"errorCorrection": "Q"
}
}'Barcodes
All supported barcode formats that can be specified using the format parameter.
AZTEC
Aztec codes are 2D barcodes that can encode a large amount of data, including text, URLs, and contact information. They are often used in transportation tickets and mobile marketing.
CODABAR
Codabar is a linear barcode that is often used in libraries, blood banks, and for airbill labels. It is simple and can encode a limited set of characters.
CODE_39
Code 39 is a linear barcode that can encode alphanumeric data. It is widely used in various industries due to its simplicity and readability.
CODE_93
Code 93 is an improved version of Code 39, offering higher density and better reliability. It is used in logistics and inventory management.
CODE_128
Code 128 is a high-density linear barcode that can encode all 128 ASCII characters. It is commonly used in shipping and packaging industries.
DATA_MATRIX
Data Matrix is a 2D barcode that can encode large amounts of data in a small space. It is often used for marking small items and electronic components.
EAN_8
EAN-8 is a shortened version of EAN-13, used for small packages where a full EAN-13 barcode would be too large. It is commonly found on small retail items.
EAN_13
EAN-13 is a linear barcode used worldwide for marking retail goods. It encodes 13 digits, including a country code and product code.
INTERLEAVED_TWO_OF_FIVE
This barcode is used primarily in the industrial and warehousing sectors. It encodes pairs of digits and is efficient for numeric data.
PDF_417
PDF417 is a stacked linear barcode that can store large amounts of data. It is often used in transportation, identification cards, and inventory management.
QR_CODE
QR Code is a 2D barcode that can store various types of data, such as URLs, contact information, and text. It is widely used in marketing and mobile applications.
UPC_A
UPC-A is a linear barcode used for tracking trade items in stores. It encodes 12 numerical digits that are unique to each product.
UPC_E
UPC-E is a shortened version of UPC-A, used on small packages where space is limited. It encodes 6 digits but represents a full 12-digit UPC-A code.
Possible errors
| Identifier | Description |
|---|---|
message.contentMustNotBeBlank |
Parameter content is required and must not be blank. |
message.formatMustNotBeNull |
Parameter format is required. |
message.foregroundColorMustBeValid |
Parameter foregroundColor must be a valid hex color string. |
message.backgroundColorMustBeValid |
Parameter backgroundColor must be a valid hex color string. |
message.widthMustBeWithinRange |
Parameter width must be within 1 and 2000 pixel. |
message.heightMustBeWithinRange |
Parameter height must be within 1 and 2000 pixel. |
message.versionMustBeWithinRange |
Parameter version must be within 1 and 40. Only if format is QR_CODE. |
message.charsetDoesNotExist |
The provided charset could not be found. |
message.charsetNotSupported |
The provided charset is not supported. |
message.errorCorrectionMustBeWithinRange |
Parameter errorCorrection must be within the specified range. |
message.layersMustBeWithinRange |
Parameter layers must be within -4 and 32. Only if format is AZTEC. |
message.dataToLargeForSpecifiedLayer |
Parameter content is to large for specified layers. Only if format is AZTEC. |
message.dataToLargeForSpecifiedShape |
Parameter content is to large for specified shape. Only if format is DATA_MATRIX. |
message.dataToLargeForSpecifiedVersion |
Parameter content is to large for specified version. Only if format is QR_CODE. |
message.numericCompactionOnlyAllowedNumericContent |
Parameter content may contain only numbers if compaction is NUMERIC. Only if format is PDF_417. |
message.contentUsesNotSupportedChars |
Parameter content contains unsupported characters. |
message.contentDoesNotMatchRequestedLength |
Parameter content contains too many or too few characters. |
message.contentContainsWrongChecksum |
Parameter content contains wrong checksum. |
It should be noted that there are a number of common error messages, which can be found in the "Possible errors" section of the general documentation.
